1.High-strength aluminum alloy material, pipe diameter Ø22mm, thickness 2mm; The surface is anodized or painted; Fixed armrests, foot rests, backrests can be folded back, the whole vehicle can be folded; 2.6 inch plastic wheels with high quality solid rubber tires; Front fork integrated die-casting molding; 3.20 inch inflatable wheels, configured with aluminum rings, with aluminum alloy handwheels (used when the hand directly drives the wheelchair). The outer and inner tubes can be combined with the rim to inflate the tire to 110% of the recommended inflation pressure for 5 minutes, and the outer tire can be completely wrapped on the rim 4.Equipped with aluminum alloy stationary brakes, with rear handle linkage self-locking device, convenient for nursing personnel to operate. 5.The fabric is made of high-quality high-strength Oxford cloth, which contains a combination of canvas inner sleeves and sewing structures, with high tensile strength; 6.Fixed handrails with PU armrest pads; 7.High-strength engineering plastic skid plate is selected. 8.Configurable height adjustable;
| Total length | 90cm |
| Total width | 53cm |
| Total high | 85cm |
| Packing size (L*W*H) | 78*28*68cm/1 |
| Fold width | 28cm |
| Backrest height | 42cm |
| Seat depth | 30cm |
| Seat width | 30cm |
| Seat height off the ground | 44cm |
| Front wheel diameter | 15cm |
| Rear wheel diameter | 53cm |
| Maximum load | 100kg |
| Net weight | 12.3kg |
Model Comparison
| Specification | AM-FS903LAJPQF9 | AM-FS874LJPF7 | AM-FS907LABH | AM-FS723LQF14 | AM-FS210ABE-61 | AM-FS874LAJ-30 | AM-FS804LABJ | AM-FS800LBF3 |
|---|---|---|---|---|---|---|---|---|
| Total length | 102 cm | 89 cm | 96 cm | 85 cm | 105 cm | 90 cm | 93 cm | 73.5 cm |
| Total width | 69 cm | 62 cm | 63 cm | 52 cm | 77.5 cm | 53 cm | 47 cm | 38 cm |
| Total height | 92 cm | 89 cm | 91 cm | 80 cm | 91.5 cm | 85 cm | 89 cm | 86.5 cm |
| Fold width | 37 cm | 26 cm | 26 cm | 35 cm | 30 cm | 28 cm | 25 cm | 58 cm ⚠️ |
| Seat width | 46 cm | 46 cm | 46 cm | 36 cm | 61 cm | 30 cm | 37 cm | 35 cm |
| Seat depth | 40 cm | 40 cm | 40 cm | 36 cm | 45 cm | 30 cm | 36 cm | 34 cm |
| Seat height | 47 cm | 49 cm | 51 cm | 48 cm | 52 cm | 44 cm | 45 cm | 49 cm |
| Backrest height | 44 cm | 38 cm | 37 cm | 27 cm | 40 cm | 42 cm | 38.5 cm | 34 cm |
| Front wheel Ø | 15 cm | 18 cm | 15 cm | 10 cm | 20 cm | 15 cm | 12.5 cm | 7.6 cm |
| Rear wheel Ø | 56 cm | 56 cm | 40 cm | 60 cm | 31 cm ⚠️ | 53 cm | 15 cm ⚠️ | 12.5 cm |
| Max load | 100 kg | 100 kg | 100 kg | —（样册未列） | 125 kg | 100 kg | 100 kg | 100 kg |
| N.W. | 14.5 kg | 11.8 kg | 13.7 kg | 10.7 kg | 17.8 kg | 12.3 kg | 6.7 kg | 6 kg |
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
