Aluminum wheelchairs are lighter. Nobody disputes that. But steel wheelchairs have advantages that spec sheets don’t always capture: they’re stiffer under load, which means less frame flex when the user shifts position, and they’re typically forty to fifty percent less expensive than an equivalent aluminum model. The AM-FS901B is our powder-coated steel manual wheelchair—eight-inch front casters with solid tires, a foldable frame, and a weight capacity that handles the average adult without the frame creaking or twisting. If you need to lift the chair into a car daily, aluminum is the better choice. If the chair stays on one floor of a house and the user values stability and cost over portability, steel is the practical answer. The 901B is for the latter scenario.
1.Steel Powder coating , beautiful and durable 2.Plastic wheels with a front wheel diameter of 200 mm (8 inch) are equipped with high-quality solid tires with a tire width of 50 mm. With integrated stamping metal crutch arm; 3.Rear wheel diameter 620 mm (24 inch) mag wheel with galvanized metal handwheel (used when the hand is directly driven) ； 4.Ssteel manual stop brake; 5.The fabric adopts PVC artificial leathe 6.Made of steel pipe with a diameter of 22mm and a thickness of 1.2mm, the movable disassembly handrail is convenient for disassembly;
| name | parameter |
| Total length | 107cm |
| Total width | 65cm |
| Total high | 89cm |
| Packing size (L*W*H/pcs). | 80*28*91cm/1 |
| Fold width | 28cm |
| Backrest height | 41.5cm |
| Seat depth | 40cm |
| Seat width | 46cm |
| Seat height off the ground | 51cm |
| Front wheel diameter | 20cm |
| Rear wheel diameter | 62cm |
| Maximum load | 100kg |
| Net weight | 18.4kg |
Model Comparison
| Specification | AM-FS809B | AM-FS809 | AM-FS901B | AM-FS874 | AM-FS903LPQF11 | AM-FS954GC | AM-FS212BCEG | AM-FS958LBCGPY |
|---|---|---|---|---|---|---|---|---|
| Total length | 106 cm | 106 cm | 107 cm | 103 cm | 100 cm | 125 cm | 111 cm | 112 cm |
| Total width | 65 cm | 64 cm | 65 cm | 66 cm | 66 cm | 66 cm | 55 cm | 53.5 cm |
| Total height | 89 cm | 86.5 cm | 89 cm | 90.5 cm | 90 cm | 120 cm | 107 cm | 104–120 cm |
| Fold width | 24 cm | 23 cm | 28 cm | 24.5 cm | 27 cm | 34 cm | 32 cm | 31 cm |
| Seat width | 46 cm | 46 cm | 46 cm | 46 cm | 46 cm | 46 cm | 41 cm | 38 cm |
| Seat depth | 40 cm | 40 cm | 40 cm | 40 cm | 40 cm | 40 cm | 40 cm | 36 cm |
| Seat height | 49 cm | 51 cm | 51 cm | 46 cm | 52 cm | 51.5 cm | 49 cm | 55 cm |
| Backrest height | 39 cm | —（样册未列） | 41.5 cm | 40.3 cm | 37 cm | 45 cm | 58.5 cm | 42 cm |
| Armrest height | 28 cm | —（样册未列） | —（样册未列） | 21 cm | 23–26 cm | —（样册未列） | —（样册未列） | 17–20 cm |
| Front wheel Ø | 20 cm | 20 cm | 20 cm | 20 cm | 20 cm | 20 cm | 15 cm | 20 cm |
| Rear wheel Ø | 61 cm ⚠️ | 58 cm | 62 cm | 58 cm | 62 cm | 62 cm | 40 cm | 51 cm (PU) |
| Max load | 100 kg | 100 kg | 100 kg | 100 kg | 100 kg | 100 kg | 100 kg | 75 kg |
| N.W. | 17.2 kg | 16.5 kg | 18.4 kg | 17.5 kg | 16 kg | 23.13 kg | 20.2 kg | 22.5 kg |
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
