The AM-CLK is an electric gynecological table with motorized height, backrest, Trendelenburg, and lithotomy positioning controlled by hand pendant or foot switch, for high-volume OB/GYN practices.
Key Specifications
| Parameter | Value |
|---|---|
| Height Range | 580–980 mm |
| Backrest Adjustment | 0–75° |
| Trendelenburg / Reverse | 20° / 12° |
| Lithotomy Positioning | Motorized (independent leg control) |
| Load Capacity | 200 kg |
| Control Pendant Rating | IPX4 |
| Memory Positions | 4 |
Features
- Motorized height, backrest, Trendelenburg, and lithotomy positioning
- Wider height range of 580–980 mm via electric actuator
- Independent leg support extension, raise, and lateral rotation for each side
- Seamless PVC-over-foam table top with gel layer in seat and backrest sections
- Removable cushion insert for the perineal cutout
- Stainless steel removable drainage tray and integrated paper roll holder
- IPX4-rated control pendant reachable from either side
- Four programmable memory positions
- Epoxy-coated steel frame with central locking pedal
Applications
High-volume OB/GYN practices performing pelvic exams, colposcopies, IUD insertions, and minor in-office procedures.
Model Comparison
| Specification | AM-KDC-Y CBYT | AM-KDC-Y CLK | AM-KDC-Y JJK | AM-KDC-Y DGN |
|---|---|---|---|---|
| Type | Electric delivery bed | Electric delivery table | Hydraulic delivery table | Electric exam table |
| Table size | 192×92 cm | 185×60 cm | 185×60 cm | 185×60 cm |
| Height range | 65–90 cm | 74–100 cm | 74–100 cm | 74–100 cm |
| Longitudinal slide | 25 cm | — | — | — |
| Trendelenburg/Reverse | 5°/5° | 10°/25° | 15°/25° | 15°/25° |
| Back plate (up/down) | 65° (up) | 75°/10° | 75°/10° | 75°/10° |
| Foot plate (up/down) | 55°/5° | — | — | — |
| Load capacity | 200 kg | — | — | — |
| Power | — | AC220V, 50Hz | AC220V, 50Hz | AC220V, 50Hz |
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
