The AM-800 is an electric dental chair with a standard left-mounted delivery system and washable PVC upholstery, for routine restorative and extraction procedures in small clinics.
Key Specifications
| Parameter | Value |
|---|---|
| Patient Weight Capacity | 135 kg |
| Seat Height Range | 460–800 mm |
| Motor | 24V DC |
| Handpiece Positions | 3 (two high-speed, one low-speed) |
| Operating Light Illuminance | 25,000–35,000 Lux |
| Delivery Arm Rotation | 180° |
| Upholstery | Seamless medical-grade PVC (4 colors) |
| Base | Cast aluminum, low-profile footprint |
Features
- Electric positioning with foot pedal and side-mounted rocker switches
- Backrest reclines from upright to fully supine with independent seat tilt for Trendelenburg positioning
- Left-mounted delivery system with three handpiece positions
- Three-way syringe, saliva ejector, and spittoon bowl with timed cup filler
- Seamless heat-welded PVC upholstery in four standard colors
- Removable armrests for patient transfer and a three-plane adjustable headrest
- LED operating light on a three-joint balanced arm
- Sealed control compartment protecting against dust and fluid ingress
Applications
Small clinics performing routine restorative work and extractions, including operatories with limited footprint.
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
