The AM-01B is a multifunctional anesthesia machine with a four-tube flowmeter system and a six-mode ventilator, for thoracic, bariatric, and prolonged surgical procedures requiring active ventilation management.
Key Specifications
| Parameter | Value |
|---|---|
| Flowmeters | Four-tube (O2, N2O), 0.1–10 L/min per channel |
| Vaporizer Positions | 2 (enflurane, isoflurane, sevoflurane; halothane optional) |
| Vaporizer Setting Range | 0.5%–5% |
| Ventilation Modes | A/C, IPPV, SIPPV, IMV, SIMV, MANUAL |
| I/E Ratio | 4:1–1:10 |
| Display | 5.4-inch LCD with waveform visualization |
Features
- Four-tube flowmeter system for finer oxygen and nitrous oxide control
- Six ventilation modes including IMV and SIMV for spontaneous breathing and weaning protocols
- I/E ratio range of 4:1 to 1:10 for prolonged expiratory time
- Two vaporizer positions across a 0.5%–5% setting range
- 5.4-inch LCD display with waveform visualization and numeric data
Applications
Surgical departments running thoracic, bariatric, and prolonged procedures where ventilation management is an ongoing clinical task.
Model Comparison
| Specification | AM-01D | AM-850 | AM-01B | AM-01 |
|---|---|---|---|---|
| Flowmeter | 3 tubes (O2/N2O/AIR) | 5 tubes (O2/N2O/AIR) | 4 tubes (O2/N2O) | 2 tubes (O2/N2O) |
| Ventilation modes | Manual, IPPV, SIPPV, IMV, SIMV | A/C, IPPV, SIPPV, IMV, SIMV, PCV, VCV, PEEP, SIGH, MANUAL | A/C, IPPV, SIPPV, IMV, SIMV, MANUAL | A/C, IPPV, SIPPV, MANUAL |
| Tidal volume | 50–1500 ml (adj), 0–1500 (disp) | 20–1500 ml (adj), 0–2000 (disp) | 0–1500 ml (adj), 50–1500 (disp) | 50–1500 ml |
| Respiratory rate | 1–99 bpm | 1–100 bpm | 1–99 bpm | 4–40 bpm |
| I/E ratio | 4:1–1:10 | 8:1–1:10 | 4:1–1:10 | 1:1.5–1:3.0 |
| PEEP | 0–10 cmH2O (electronic) | 0–2.0 kPa | — | — |
| O2 concentration | — | 21%–100% | — | — |
| Display | 10.4″ TFT | — | — | — |
| Vaporizers | 2 (with 2 PA-IV) | 2 (Enflurane/Isoflurane/Sevoflurane/Halothane) | 2 (Halothane optional) | 2 (Halothane optional) |
| Backup power | 30 min–4 h | — | — | — |
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
