The AM-01 is a premium anesthesia workstation with dual flowmeters, a four-mode integrated ventilator, and two vaporizer positions, for general surgery, orthopedics, and gynecology requiring controlled ventilation.
Key Specifications
| Parameter | Value |
|---|---|
| Drive | Pneumatic, electrically controlled |
| Flowmeters | Dual (O2, N2O), 0.1–10 L/min each |
| Oxygen Flush | 25–75 L/min |
| Vaporizer Positions | 2 (enflurane, isoflurane, sevoflurane; halothane optional) |
| Vaporizer Setting Range | 0.5%–5% |
| Ventilation Modes | A/C, IPPV, SIPPV, MANUAL |
| Tidal Volume | 50–1500 ml |
| Respiration Frequency | 4–40 bpm |
| I/E Ratio | 1:1.5–1:3.0 |
| Display | LED |
Features
- Dual flowmeters for oxygen and nitrous oxide with 0.1–10 L/min control per channel
- Oxygen flush of 25–75 L/min for rapid breathing circuit refill
- Two vaporizer positions for enflurane, isoflurane, or sevoflurane with halothane optional
- Four ventilation modes: A/C, IPPV, SIPPV, and MANUAL
- Tidal volume from 50 to 1500 ml and respiration frequency from 4 to 40 bpm
- LED display of airway pressure, tidal volume, minute ventilation, and frequency
Applications
General surgery, orthopedics, gynecology, and any procedure requiring controlled ventilation under general anesthesia.
Model Comparison
| Specification | AM-01D | AM-850 | AM-01B | AM-01 |
|---|---|---|---|---|
| Flowmeter | 3 tubes (O2/N2O/AIR) | 5 tubes (O2/N2O/AIR) | 4 tubes (O2/N2O) | 2 tubes (O2/N2O) |
| Ventilation modes | Manual, IPPV, SIPPV, IMV, SIMV | A/C, IPPV, SIPPV, IMV, SIMV, PCV, VCV, PEEP, SIGH, MANUAL | A/C, IPPV, SIPPV, IMV, SIMV, MANUAL | A/C, IPPV, SIPPV, MANUAL |
| Tidal volume | 50–1500 ml (adj), 0–1500 (disp) | 20–1500 ml (adj), 0–2000 (disp) | 0–1500 ml (adj), 50–1500 (disp) | 50–1500 ml |
| Respiratory rate | 1–99 bpm | 1–100 bpm | 1–99 bpm | 4–40 bpm |
| I/E ratio | 4:1–1:10 | 8:1–1:10 | 4:1–1:10 | 1:1.5–1:3.0 |
| PEEP | 0–10 cmH2O (electronic) | 0–2.0 kPa | — | — |
| O2 concentration | — | 21%–100% | — | — |
| Display | 10.4″ TFT | — | — | — |
| Vaporizers | 2 (with 2 PA-IV) | 2 (Enflurane/Isoflurane/Sevoflurane/Halothane) | 2 (Halothane optional) | 2 (Halothane optional) |
| Backup power | 30 min–4 h | — | — | — |
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
