The AM-Y08A is an electric surgical table with five independent tabletop sections and electric drive on height, Trendelenburg, lateral tilt, back, and leg sections, for multi-specialty operating rooms.
Key Specifications
| Specification | Imperial (inch) | Metric (cm/degree) |
|---|---|---|
| Table Size | 79″ × 19.7″ | 201 cm × 50 cm |
| Lifting Range | 25.6″ – 37.4″ | 65–95 cm |
| Trendelenburg / Reverse | – | -25° / 20° |
| Lateral Tilt (L/R) | – | -20° / 20° |
| Back Plate (Up/Down) | – | -89° / 10° |
| Battery Capacity | – | ≥50 operations |
Features
- Five independent tabletop sections for multi-specialty positioning
- Electric drive on height, Trendelenburg, lateral tilt, back, and leg sections
- Handheld controller with surgeon-specific presets
- 24V DC low-voltage control system
- High-strength melamine resin board bed panel
- Optional memory foam mattress for long procedures
- AC/DC dual power with battery capacity of 50 or more operations
Applications
Neurosurgery, cardiac, orthopedic, and gynecological procedures from a single platform, with translation for C-arm imaging access.
Model Comparison
| Specification | AM-Y09B CDW | AM-Y09B GK (Ortho) | AM-Y09B DHYX (Imaging) | AM-19A ZN |
|---|---|---|---|---|
| Table size | 217×55 cm | 217×55 cm | 240×53 cm | 207×50 cm |
| Height range | 55–105 cm | 68.5–113.5 cm | 70–100 cm | 65–90 cm |
| Lateral tilt | 20°/20° | 20°/20° | 18°/18° | ≥20°±5° |
| Trendelenburg/Reverse | 30°/30° | 30°/30° | 22°/22° | ≥30°±5° |
| Back plate | 90°/40° | 90°/40° | 60°/18° | up ≥80°/down ≥35° |
| Kidney bridge | 12 cm | 12 cm | — | ≥120 mm |
| Longitudinal slide | 30 cm | 35 cm | 26 cm (electric) | ≥360 mm |
| Load capacity | 250 kg | 350 kg | — | — |
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
