The AM-8000IIA is a standard pediatric dental unit with electric positioning, a three-position delivery system, and a 25,000–40,000 lux LED operating light, for children approximately 3 to 12 years old.
Key Specifications
| Parameter | Value |
|---|---|
| Patient Age Range | Approx. 3–12 years |
| Seat Height Range | 470–810 mm |
| Motor Power | 220V/50Hz (110V/60Hz option) |
| Handpiece Positions | 3 |
| Operating Light Illuminance | 25,000–40,000 Lux (adjustable) |
| Upholstery | Seamless medical-grade PVC (blue) |
| Base | Cast iron, powder-coated finish |
Features
- Electric positioning with independent backrest recline and Trendelenburg capability
- Seamless medical-grade PVC upholstery that is cleanable and replaceable
- Three handpiece positions with three-way syringe, saliva ejector, and cuspidor with cup filler
- Rocker-switch controls without touchscreen or software dependencies
- LED operating light on a four-joint balanced arm with rotary intensity adjustment
- 220V/50Hz motor with a 110V/60Hz option
- Modular, swappable control board for field serviceability
- Standard 4 mm pneumatic connectors
Applications
Children’s clinics, community health centers, and budget-conscious practices that require a reliable, simple-to-maintain pediatric unit.
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
