A transit wheelchair isn’t measured by how well the user can propel it—it’s measured by how easily the caregiver can lift it. When a spouse in their seventies is folding the chair, hoisting it into the trunk of a Corolla, and unfolding it again at the doctor’s office, every kilogram matters. The AM-FS804LABJ is our lightweight aluminum transit chair, designed specifically for the caregiver who loads and unloads the chair multiple times per day. The small rear wheels save weight and reduce the folded package size, and the aluminum frame drops the overall weight by about three kilograms compared to a steel transit chair. That doesn’t sound like much until you’ve lifted both into a trunk at the end of a long day. This is the chair I recommend when the caregiver’s back is as important as the user’s comfort.
1.Superior comfort. 2.Aluminum frame with good safety performance, 3.Wheels with high-quality tires ensure shock absorption and durability.、 4.Enjoy a cozier experience as you roll around in this wheelchair.
| Frame: | Aluminum oxidatio foldable structure, good safety performance |
| Front wheel: | 5-inch (125mm) rubber solid wheels with high-strength engineering plastic wheels and non-inflatable solid tires. |
| Rear wheel: | 6″(150mm) PU wheels configured with high-strength polymer wheels, non-inflatable solid tires. |
| Brake: | Aluminum alloy brakes, good braking performance |
| Seat cushion: | Oxford nylon cloth cover is adopted, which contains a combination of canvas inner sleeves of more than 300d, and the tensile strength is high. |
| Armrest: | Flip-up armrests. |
| Foot rests: | Flip-up foot rests. |
| name | parameter |
| Total length | 93cm |
| Total width | 47cm |
| Total high | 89cm |
| Packing size (L*W*H/pcs). | 75*25*66cm/1
|
| Fold width | 25cm |
| Backrest height | 38.5cm |
| Seat depth | 36cm |
| Seat width | 37cm |
| Seat height off the ground | 45cm |
| Front wheel diameter | 12.5cm |
| Rear wheel diameter | 15m |
| Maximum load | 100kg |
| Net weight | 6.7kg |
Model Comparison
| Specification | AM-FS903LAJPQF9 | AM-FS874LJPF7 | AM-FS907LABH | AM-FS723LQF14 | AM-FS210ABE-61 | AM-FS874LAJ-30 | AM-FS804LABJ | AM-FS800LBF3 |
|---|---|---|---|---|---|---|---|---|
| Total length | 102 cm | 89 cm | 96 cm | 85 cm | 105 cm | 90 cm | 93 cm | 73.5 cm |
| Total width | 69 cm | 62 cm | 63 cm | 52 cm | 77.5 cm | 53 cm | 47 cm | 38 cm |
| Total height | 92 cm | 89 cm | 91 cm | 80 cm | 91.5 cm | 85 cm | 89 cm | 86.5 cm |
| Fold width | 37 cm | 26 cm | 26 cm | 35 cm | 30 cm | 28 cm | 25 cm | 58 cm ⚠️ |
| Seat width | 46 cm | 46 cm | 46 cm | 36 cm | 61 cm | 30 cm | 37 cm | 35 cm |
| Seat depth | 40 cm | 40 cm | 40 cm | 36 cm | 45 cm | 30 cm | 36 cm | 34 cm |
| Seat height | 47 cm | 49 cm | 51 cm | 48 cm | 52 cm | 44 cm | 45 cm | 49 cm |
| Backrest height | 44 cm | 38 cm | 37 cm | 27 cm | 40 cm | 42 cm | 38.5 cm | 34 cm |
| Front wheel Ø | 15 cm | 18 cm | 15 cm | 10 cm | 20 cm | 15 cm | 12.5 cm | 7.6 cm |
| Rear wheel Ø | 56 cm | 56 cm | 40 cm | 60 cm | 31 cm ⚠️ | 53 cm | 15 cm ⚠️ | 12.5 cm |
| Max load | 100 kg | 100 kg | 100 kg | —（样册未列） | 125 kg | 100 kg | 100 kg | 100 kg |
| N.W. | 14.5 kg | 11.8 kg | 13.7 kg | 10.7 kg | 17.8 kg | 12.3 kg | 6.7 kg | 6 kg |
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
