The AM-3000 is an integrated adult dental unit combining a 160 kg-capacity patient chair, a four-position delivery system, a 40,000–60,000 lux LED operating light, and a ceramic cuspidor, for general restorative and endodontic practice.
Key Specifications
| Parameter | Value |
|---|---|
| Patient Weight Capacity | 160 kg |
| Seat Height Range | 450–820 mm |
| Motor | 24V DC worm gear drive |
| Handpiece Positions | 4 (two high-speed fiber optic, one low-speed, one spare) |
| Operating Light Illuminance | 40,000–60,000 Lux (3-step adjustable) |
| Color Temperature | 4500 K |
| CRI | 90+ |
| Delivery Arm Rotation | 270° |
| Cuspidor | Ceramic, 90° rotation, auto-flush on exit position |
Features
- Independent backrest and seat recline with synchronized movement via single foot pedal
- 24V DC worm gear drive for quiet operation with sufficient torque
- Seamless medical-grade PVC upholstery with heat-welded seams, available in six standard colors
- Double-articulated headrest with angle and extension adjustment
- Balanced swing-arm delivery system with 270° rotation
- Four handpiece positions with independent water and air controls and preset memory
- Body-temperature heated three-way syringe
- Membrane-switch control panel for tactile, look-away adjustment
- LED operating light on a six-joint balanced arm
- Ceramic cuspidor that rotates 90° and flushes automatically at exit position
Applications
General restorative dentistry, endodontics, and routine surgical extractions in new practices, growing clinics, and operatories being added for patient volume.
CE marking and ISO 13485 documentation can be confirmed for the specific model, configuration, legal manufacturer, and destination market.
Frequently Asked Questions
What specifications should I review for this model?
Key specifications including dimensions, capacity, power requirement and material composition are provided in the model datasheet. Contact us with your project requirements for the complete specification sheet.
What documents are available for import?
Datasheet, user manual, packing information and applicable conformity documents are confirmed per destination market. Registration requirements vary by country and are reviewed project by project.
Can I request a sample or reference installation?
Sample availability and reference installation details are confirmed based on the product category and order volume. Contact us with your specific requirements.
