| Pneumatically driven and electrically controlled system |
| Built-in ventilator, 8.4” LCD display screen |
| Closed; Semi-Closed; Semi-Open wotking mode |
| Applied for Adult and Pediatric |
| Main technical specifications: |
| Gas requirement: Medical oxygen and nitrous oxide with a pressure ranging from O2 & NO2: 0.32~0.6 MPa. |
| 5-tubes Flowmeters, O2 & N2O & Air ; 0.1L/Min ~ 10L / Min; |
| Oxygen Flush: 25~75 L / Min |
| Respiration Mode: A/C,IPPV,SIPPV,IMV,SIMV,VCV,PCV,PEEP,SIGH,MANUAL |
| Tidal Volume: Adjustable range: 20 ~ 1500 ml, Display range:0~2000ml |
| I/E Ratio: 8:1 ~ 1:10 |
| Two vaporizers: Enflurane/ Isoflurane/Sevoflurane (Optional:Halothane) |
| Vaporizer Setting Range: 0.5%~5% |
| Respiration Frequency : 1~100 bpm; |
| Lung compliance: ≤30 mL / kPa |
| IMV frequency: 1~20 bpm; |
| PEEP: 0 ~ 2.0 kPa |
| Ptr: -1.0kPa ~ 2.0 kPa |
| CO2 absorber capacity : 1 kg |
| Inspiratory Plateau: 0~1 S ; |
| O2 Concentration: 21%~100% |
| Optional: Patient monitor |
| Alarm parameters: upper/lower limit of airway pressure,tital volume exceed limitation,no tidal volume output,apnea, |
| oxygen concentration, AC power malfunction,Battery low power. |
